Notes:
The standard color: light gray and desert tan.
Surface type: concave top or grit top(extra fine, fine and medium grit).
Custom color and size can be available upon request.
GLOBALGRID™ Mini-mesh Grating(ADA Compliant Decking) is designed specially for application in the commercial and private marina industry for ADA compliance and light penetration. With the ADA compliant 1/2” open area for both cross bar and bearing bar, GLOBALGRID™ mini-mesh grating allows light to pass down (with sufficient natural light for fishery and vegetation below the dock). The mesh structure is also ideal for managing ocean waves or hurricane winds (to pass up and through). Special clip assemblies (Type W) are provided for attaching the GLOBALGRID™ mini-mesh grating to the substructure of any type. The GLOBALGRID™ mini-mesh grating is the ideal replacement for the conventional decking materials.
Characteristics:
• Full ADA Compliance
• Light Penetration
• Effective Management of Ocean Waves and Hurricane Winds
• Permanent Resistance to Slipping and Sliding
• Corrosion Resistant
• Easy Access to Utility
• Ergonomic and Anti-Fatigue
• Easy to Fabricate and Install
• Appearance(Uniform and Attractive)
• Maintenance Free
• Fire Retardant
• Long Service Life
• Economical
Typical Used Fields:
• Commercial Marina • Private Marina
Typical Applications:
• Docks • Decks • Walkways • Platforms
• Gangways • Knee Brackets • Transition Plates • Utility Cover • Fingers
GLOBALGRID™ Standard Decking Parameters:
Panel Thickness |
Open Mesh |
Panel Size |
Unit Weight (lbs/sq.ft.) |
1” |
1/2”x1/2” |
4’x12’ |
3.21 |
1-1/5” |
1/2”x1/2” |
3.28’x13.12’ (1mx4m) |
3.53 |
1-1/5” |
1/2”x1/2” |
4’x12’ |
3.53 |
1-1/2” |
1/2”x1/2” |
3.28’x13.12’ (1mx4m) |
4.46 |
1-1/2” |
1/2”x1/2” |
4’x12’ |
4.46 |
GLOBALGRID™ Mini-mesh Grating
