Shapes |
1.0” T-Bar |
1.0” I-Beam |
1.25” I-Beam |
1.5” T-Bar |
1.5” I-Beam |
2.0” T-Bar |
|
Opening |
12%, 18%, 25%, 35%, 38% |
40% 50% 60% |
40% 50% 60% |
12% 25% 38% |
40% 50% 60% |
33% 50% |
|
Width |
3ft., 4ft., 5ft. | |||||
|
Length |
8ft., 10ft., 12ft., 20ft. | |||||
Notes:
* Standard panels come with cross bar spacing of 6” or optional 12” on center.
* Custom color and size are available upon request.
* Panel size are specified: Width x Length. Width is the measurement from end to end of the cross bar. Length is always the bearing bar length.
|
Type |
Thickness |
Bar Space |
Open Space |
Open Area |
Unit Weight (Lbs./Sq.Ft.) |
|
T1810(ADA) |
1.0” |
1.625” |
0.375” |
18% |
2.50 |
|
T3510 |
1.0” |
1.625” |
0.875” |
35% |
2.01 |
|
T1210(ADA) |
1.0” |
1.5” |
0.21” |
12% |
2.97 |
|
T2510(ADA) |
1.0” |
1.5” |
0.5” |
25% |
2.52 |
|
T3810 |
1.0” |
1.5” |
0.9” |
38% |
2.09 |
|
I4010(ADA) |
1.0” |
0.6” |
0.4” |
40% |
3.50 |
|
I5010 |
1.0” |
0.6” |
0.6” |
50% |
2.97 |
|
I6010 |
1.0” |
0.6” |
0.9” |
60% |
2.29 |
|
I40125(ADA) |
1.25” |
0.6” |
0.4” |
40% |
4.06 |
|
I50125 |
1.25” |
0.6” |
0.6” |
50% |
3.56 |
|
I60125 |
1.25” |
0.6” |
0.9” |
60% |
2.77 |
|
T1215(ADA) |
1.5” |
1.5” |
0.21” |
12% |
4.01 |
|
T2515(ADA) |
1.5” |
1.5” |
0.5” |
25% |
3.42 |
|
T3815 |
1.5” |
1.5” |
0.9” |
38% |
2.91 |
|
I4015(ADA) |
1.5” |
0.6” |
0.4” |
40% |
4.51 |
|
I5015 |
1.5” |
0.6” |
0.6” |
50% |
3.91 |
|
I6015 |
1.5” |
0.6” |
0.9” |
60% |
3.30 |
|
T3320(ADA) |
2.0” |
1.0” |
0.5” |
33% |
4.19 |
|
T5020 |
2.0” |
1.0” |
1.0” |
50% |
3.27 |
|
I1060(ADA) |
1.0” |
0.31” |
0.47” |
60% |
3.03 |
|
I1560(ADA) |
1.5” |
0.31” |
0.47” |
60% |
4.20 |
GLOBALGRID™ Pultruded Grating is assembled by pultruded bearing bar("I" beam or "T" beam) and cross bar with a high percentage of fiberglass within the laminate, providing durability, extremely high unidirectional strength and stiffness. The cross bar is mechanically interlocked and epoxy bonded to the bearing bar.
Characteristics:
• Corrosion resistant
• High stiffness & light weight
• Impact resistant
• Fire retardant
•
Slip resistant
• Unidirectional strength
• Non-conductive, non-magnetic, non-sparking
•
Maintenance free
• Easy to fabricate and install
Typical used fields:
• Marine • Refining • Offshore • Pulp
& Paper
• Chemical • Plating • Electronics •
Food & Beverage
• Water and Wastewater treatment
Typical applications:
• Flooring • Platforms • Walkways • Assembly
Lines
• Trench Covers • Stairs • Catwalks • Ramps
GLOBALGRID™ Standard Grating Parameters:
GLOBALGRID™ Pultruded Grating
